Voron 2.4 R2 X axis artifacts

[Timmyklus]

Printer Model

Voron 2.4 R2

Extruder Type

Clockwork 2

Cooling Type

Afterburner

Hey all,
Just completed building my voron with the help of a buddy. (He built most of it) he has built 5 machines so far.

The issue I’m having is in the X axis, I am getting a very faint vibration indicated on the print surface. The Y axis is super smooth. If I rotate the part at a 45 degree, the issue moves to both sides of the cube.

In the image below I have printed the same exact part with same settings but I just changed the orientation 90 degrees. I checked the frequency of the “wiggle” and it doesn’t appear to be the same pitch as the belts.

My thoughts are linear rail choppiness would be causing the issue in only the X axis. I tried packing the bearing but it didn’t seem to help

Thoughts? Ideas to try?



[NoGuru]

Congrats on the new build!

What I think it might be is your idler bearings. If you look at the pattern is seems to be lined up with the teeth on the belts?
Here is one of the best guides to go though with a new build https://ellis3dp.com/Print-Tuning-Guide/articles/troubleshooting/vfas.html



[Timmyklus]

I checked the defect spacing and sure enough, it is 2mm!

What about the idler would cause this? Guessing it would only be the toothed pulley? And not the smooth idler behind the toothed.



[Spydyr]

Congrats. I have seen this on my Sapphire Plus. It was a bearing on a toothed idler. I have also seen this when others replace the toothed idlers with bearing.



[NoGuru]

I checked the defect spacing and sure enough, it is 2mm!

What about the idler would cause this? Guessing it would only be the toothed pulley? And not the smooth idler behind the toothed.

Could be blet tension, good belt mixed with cheap idlers or the other way around or a racked gantry.
That's all I can think of now, oh wait, could be steps and motor current as well.



[Timmyklus]

So I had some extra idlers. Guessing they were from the same batch as what was previously installed. Put the new ones in and set belt tension per the freq Instructions, it seems a little better.

I ordered some new idlers from west3D, once those show up, I’ll swap those, retention and redo my resonance testing and see how it looks.

Thanks again for the help!!!



[NoGuru]

Make sure you have the gantry racked and even belt tension on both sides.
Shake n Tune can help you get the belts equal or at the least help visualize them.

GitHub - Frix-x/klippain-shaketune: Klipper streamlined input shaper workflow and calibration tools

Klipper streamlined input shaper workflow and calibration tools - Frix-x/klippain-shaketune

github.com
