Solved First time build 2.4 using 2.4 kit cant home

[sharpen047]

Printer Model

Siboor voron 2.4 r2 aug

Extruder Type

Clockwork 2

Cooling Type

Stealthburner

Hey, guys. I just finally assembled my 2.4 kit from siboor using the aug variant.
Ive corrected the stepper directions in klipper but it shows z and x are always triggered when pressed or not. Z has an induction probe and x has a limit switch on the carriage.
No matter what i do, x and z are triggered when i query endstops.
one thing ive noticed is that both of these go through the canbus board. While everything else seems to be working like temp, hotend and RGB, i cant help but think this is a setting or something simple.
Any help would be appreciated.
Thanks



[shiftingtech]

What kind of a voron has the z endstop (not z probe! Those are not interchangeable!) Attached to the canbus board?

But beyond that, it sounds like you're probably on the right track...

What are those two endstop_pins set to?



[NoGuru]

What control boards and what do you have the PINS set too?



[sharpen047]

Ok so i found the issue and it was all user error. i needed to pull up the x switch input with the ^. The cartographer probe needs its own calibration setup for first time use. actually like it very much.
my pi came with klipper preinstalled and ive had to change the config but once i set up the canbus stuff, installed the 'driver' for the cartographer, it had a macro setup for setting up the probe by calibrating it.
i followed the directions here

Calibration | Cartographer 3D

docs.cartographer3d.com

ive used induction probes before and they werent very consistent but this eddy current sensor is .01 mm tolerance when leveling. very happy with it so far.
i might want to make a video on all the differences with the voron 2.4 aug kit from siboor since that seems to be the difference between the older cable chain variants that ive heard about in the past.



[TerryFrench]

Ok so i found the issue and it was all user error. i needed to pull up the x switch input with the ^. The cartographer probe needs its own calibration setup for first time use. actually like it very much.
my pi came with klipper preinstalled and ive had to change the config but once i set up the canbus stuff, installed the 'driver' for the cartographer, it had a macro setup for setting up the probe by calibrating it.
i followed the directions here

Calibration | Cartographer 3D

docs.cartographer3d.com

ive used induction probes before and they werent very consistent but this eddy current sensor is .01 mm tolerance when leveling. very happy with it so far.
i might want to make a video on all the differences with the voron 2.4 aug kit from siboor since that seems to be the difference between the older cable chain variants that ive heard about in the past.

Quick question if you do not mind, what is your klipper setting for the SB's LEDs?
I have the Siboor kit also with the cartographer probe, SB 2209 RP2040... and I don't seem to get the SB LED (connected on the EBB) to light up.
Before I spend a lot more time troubleshooting, I'd love to compare the led settings as I suspect a SW issue.
Thanks!



[NoGuru]

Quick question if you do not mind, what is your klipper setting for the SB's LEDs?
I have the Siboor kit also with the cartographer probe, SB 2209 RP2040... and I don't seem to get the SB LED (connected on the EBB) to light up.
Before I spend a lot more time troubleshooting, I'd love to compare the led settings as I suspect a SW issue.
Thanks!

You should probably start a new thread so anyone can jump in and help. Also post your printer.cfg as a txt file and if you have a separate LED config as well.
